BENCH-MOUNTED ROUTER TF 1400 230V SET

BENCH-MOUNTED ROUTER TF 1400 230V SET

Strengths and benefits Dual extraction connector Simple routing height adjustment with a crank handle Arched routing hood for safe routing and optimised extraction Router module...

Brand :FESTOOL

Type :Spares

Code :

Availability :

R 28,776.32

Strengths and benefits

  • Dual extraction connector
  • Simple routing height adjustment with a crank handle
  • Arched routing hood for safe routing and optimised extraction
  • Router module can be replaced by further CMS modules

Main applications

  • All kinds of routing work: routing rebates, recesses, curves and shapes
  • Routing shapes and curves at the ball bearing guide
  • Jointing work at the stop

Items Included

    operation tool, module support, assembly lugs, router stop, press-down fixture, guard, ?? 8 mm clamping collet, chip deflector, basic unit with foldaway legs, ?? 12 mm clamping collet, copying ring ?? 30 mm, extraction hood, top, router OF 1400 EBQ-Plus, side stop with fine setting

Technical Details

  • weight 4,5 kg
  • Working height with legs 900 mm
  • Power consumption 1400 W
  • Connection ?? d/e 27/36 mm
  • Table dimensions 585 x 400 mm
  • Max. cutter diameter 60 mm
  • Table height, legs folded away 316 mm
  • Table height, legs unfolded 900 mm
  • Idle engine speed 10000-22500 min???
  • Dimensions module support 578 x 320 mm
  • Weight module support 10,1 kg
  • Basic unit weight 10,8 kg
  • Weight (set) 25,4 kg

Commercial Information

  • Net weight 0,000 kg
  • Gross weight 0,000 kg
  • Country of origin DE
  • PU 1
  • SU 1

Industry

Wood

Quantity In Pack

1
